Additive dosing units

Automatic injection of additives into petroleum products during loading — dosed by recipe, included in custody metering, with no manual work.

Up to 6 additive lines in one unit
Dosing range 250–1,000 ppm, accuracy 0.25 % by volume
Additive tank 200 L to 2 m³
Open frame, container or mobile on a trailer chassis
Lead time from 3 months

Request a quote for this product Datasheet (PDF)

How it works

Four steps, no manual work

Set the recipe

The operator selects the product and dose (ppm or g/m³) at the workstation. Recipes are stored in the controller.
Inject before the meter

Additive is injected upstream of the custody meter, so the delivered quantity already includes it.
Dose with the flow

The dosing pump follows the loading flow; each additive line is metered by volume or mass.
Stop automatically

When the set dose is reached, a tight shut-off valve closes the line. Every batch is logged.

Design features

Built for corrosive additives and cold winters

Stainless steel additive tank

Resists corrosive additives.
Heat tracing and insulation

Additives stay pumpable in winter; operation from −40 °C to +55 °C.
Level control

Level gauge with high/low alarms, sight glass, drain, breathing valve with flame arrester.
Pumps matched to the additive

Transfer pump to fill the tank; gear, diaphragm or plunger dosing pump.
Metering integrity

Filters, check valves, relief valve and Class A tight shut-off valves prevent back-flow, leaks and dosing errors.
Easy service

Removable cladding panels give full access.

Applications

What it is used for

Branded fuels

Performance additive packages dosed by recipe for each product.
Any additive to customer specification

Up to 6 additives in one unit, each on its own line and recipe.
Aviation: FSII injection

Fuel system icing inhibitor injected into jet fuel during fuelling, with chemical-resistant seals and stainless steel wetted parts.
Fits your existing terminal

The unit can be added to existing loading bays and connected to your existing additive tanks and control system.

Technical data

Unit

Value

Parameter

—

°C / °F

—

L / US gal

% by volume

ppm

—

Volumetric or mass

200–2,000 / 53–528

0.25

250–1,000

up to 6

Additive metering

Additive tank

Dosing accuracy

Dosing range

Additive lines

from 3 months

Ex db [ib] op is IIB T4 Gb — designed to IECEx / ATEX requirements

−40 to +55 / −40 to +131

Lead time

Explosion protection

Ambient temperature

Open frame, container, mobile on trailer chassis

Execution

Built to customer specification · Turnkey delivery · 24-month warranty

Options

Additional additive lines (up to 6)
Containerised or mobile execution
Heat tracing and insulation
Connection to existing additive tanks
Integration with your control system

Standards and certificates

Designed and manufactured to the requirements of:

IECEx / ATEX
EAEU TR CU

Downloads

Datasheet PDF →

Questionnaire for quotation DOCX →

Automation

Controlled by AVRON automation

Recipes, flow-proportional dosing and batch records run in the same control system as your loading bays — one operator workstation for loading and dosing.

See how the control system works
